Fully automatic glue machine for doors and windows


2117 0


Sabtiya.com Stores

Sabtiya.com Stores المزيد من منتجات

Performance characteristics:
This equipment is a special equipment for sealing sealant between profiles and glass in the process of rectangular doors and windows. This equipment adopts well-known numerical control system and servo motor, automatic control of work flow, automatic completion of gluing process, simple operation, convenient setup, time-saving and labor-saving, uniform and beautiful gluing surface. The equipment uses 20L barreled sealant, which greatly reduces the cost of materials. It is the necessary equipment in the automatic processing and manufacturing system of doors and windows.
Equipment advantages:
PLC control system, touch-screen man-machine interface, easy and convenient operation.
It adopts automatic size measuring system and automatic corner system.
Each corner of the glue can be adjusted separately. The width of the glue before and after the corner is the same, and the glue will not overflow after the corner. Glue density is higher than that in industry.
Before and after the corner, the glue supply time and switch glue time can be adjusted.
The special glue supply and glue pressing device avoids the instability of the traditional glue supply and the phenomenon of glue leakage.
The size automatic compensation system is used to make up for the glue effect which is not equal to the diagonal of the doors and windows.
Technical parameters:
Input voltage: 220V 50HZ
Power: 2KW
Air pressure: 0.4-0.8MPa
Maximum machining size: 1500 x 2700mm
Minimum machining size: 300 x 300mm
Automatic processing thickness: < 100mm
Outline size: 3000mm * 2000mm * 1500mm
Specifications for plastic: 20L barrels (straight barrels)
