3*2M 420MPA glass art water jet cutting machine Chinese manufacturer with CE

SKU: wmt3020-al

976 0

EGP1.00

Sabtiya.com Stores



Sabtiya.com Stores المزيد من منتجات



CHANNELARK 420Mpa 3 axis glass CNC water jet cutting machine



Advantage:



1.37KW SIEMENS MOTOR

2.Schneider electric components

3.seperated body to make more stable cutting effect and better accuracy after cutting a long time.

4.free abrasive sand feeding system

5.we have the most convenient automatic abrasive sand removing and recycling system

6.imported American intensifier

7. Double anchor, an effective solution for the jitter of gravity when cutting, to ensure the accuracy.

8. steel beams, after heat treatment, to prevent deformation

9. Bellows can effectively prevent dust, airtight is better.

10. the linear guider is soaked in the oil to make the accuracy of the machine longer. can make sure 5 years accuracy at least.

11.  Legitimate WINDOWS 7 system

12. SIEMENS PLC

13. voltage can be 380/220/418V.

14.linear guider and ball screw brand is TBI, and now we have a new technology to put the linear guider and ball screw into the oil so that make the accuracy longer.

15. Servo variable pump so that the pump working is more stable.

16. two years warranty for the whole machine.







Main technical parameter of water jet cutting machine
Intensifier Pump Item Parameter
Model CAWJ3742Z
motor SIEMENS
Method of Direction Regulation Electronic Direction Regulation
Pressure Range 50-420MPA, continuous pressure is 330-380Mpa
Maximum Flow of Hydraulic Pump 90 L/min
Maximum Discharge Capacity 3.7L/min
Maximum Diameter of Gem Nozzle 0.33mm
Power of Master Motor 37KW
Power Source 380V/50HZ, can do 220V/60HZ, 412V
Cutting Table Item Parameter
X axis characteristic Adapting the one-off extrusion forming aluminum alloy, 2000MM LENGTH. the cutting table width is 2200mm
Y axis characteristic Cast iron used as foundation base , 3000MM LENGTH.the cutting table length is 3200mm.
Z axis characteristic Z axis double linear guide and four sliding block , 150MM, CAN DO 200MM
control accuracy ±0.01mm, cutting accuracy is

±0.1mm, reposition accuracy:

±0.02mm, max travelling speed:6000mm/min





Ball screw,linear guide TBI, TAIWAN
Table structure Separated body, can be delivered by one 20’FCL container
Driving way Servo drive system
CNC system Ncstudio ,Fagor
Servo motor SIEMENS motor.
Cutting head Casting structure and concrete structure
Sealing way Whole piece sealing,cancelling dustproof cloth on X,Y,Z axis
Loading weight water tank Wall thickness is 6mm,using fluorocarbon coating, Can antirust at least 5 years.
CNC Controller Item Parameter
Control Method CNC
Display Size 19inch LCD
Model of Cutting Text DXF
Model of Computer Industrial Control Computer
Operating System Windows 7
PLC SIEMENS
Cutting software advantage Auto save and transfer common parameter
Controller displace Can be fit to suitable place at own will
Automitic Abrasive Feeder Item Parameter
Founction Sand storage and sand delivery
Operating No need electrocnic control,sample operation
Capacity 200 kg for 8 -10hours
Pressure 0.3-0.6Mpa compresses gas pressure
Color White
Deionization System Item Parameter
Water pressure 0.15Mpa~0.6Mpa
Water temperature 5°C~50°C
Environment temperature 5°C~50°C
Relative humidity ≤95%(25°C)
Water turbidity <20FTU
Wireless Handle Parameter






Founction Wireless controlling waterjet
Display Real- time display condition of X,Y,Z axis
Settings Zero point, on/off valve set, X,Y,Z axis moving
Technology Advanced technology



We also have 2015 new model automatic abrasive removing system . no need installation, can be used for any brand water jet cutting machine!











CUTTING SAMPLE















DELIVERY AND PACKING:







After Service:

We can provide overseas installation and training service. 24 hours in 7 days a week respond. and respond time is no more than 12 hours.



provide two years warranty time for the whole machine. easy-wear parts replace cost is very low.





Contact information:



Water Jet Glass Cutting – How is it Done

It’s true that when it comes to glass, it is indeed a brittle material, but that doesn’t mean that it cannot be cut. In fact, by using an abrasive water jet glass can be cut quite easily and the results are generally amazing. Most of the times though, glass is going to be cut for artistic purposes.

Quality of glass

Since there are different types of glass, some of them can be cut easier than the rest. In general though, thicker glass is a lot less easier to cut compared to the thinner type. The temperature at which the glass was tempered is also an important factor that influences the difficulty of cutting the glass. If the temperature was high, then the glass becomes brittle and can shatter easily.

Water delivery and abrasive

During the piercing of the glass, the timing of the abrasive delivery is essential. The recommended pressure should be between ten to twenty thousand PSI and the abrasive should hit the glass almost at the same time as the water starts to flow. If it doesn’t, then it’ll cause the glass to crack.

The glass’ support

The glass should be properly supported on the bottom side by using something that’s both soft and can offer even support so the jet won’t frost the bottom surface. For this very purpose, waterjet brick is an excellent choice.

The part’s design

If you’re designing a part cut from glass, there are a few adjustments that can be made for minimizing of any possible cracking may have on the part. You should also know that there is a wide range of piercing methods that can be easily used with glass. With a great setup, you’ll realize that any of them can be very simple to use, but it’s true that some of them are a bit better than others. Therefore, if you’re having trouble getting a great pierce with glass, just consider a different piercing method.

If you’re planning on cutting something that has multiple pierce points, there is a much higher chance it’s going to crack at a minimum of one pierce. That is why before you begin, you should pre-pierce all the start holes and lastly, cut all the other features. In this case, even if something were to crack, you’ll be able to just throw it away and start again without wasting too much money and time.



Other things to consider: Temperature

You need to be on the lookout for sudden changes in temperature between cold air and the hot water tank since this can cause your glass to shatter. For instance, if you just pulled a freshly cut piece of glass out of hot water, you shouldn’t hose it with cold water at all. Instead, wait until it cools down a bit or just let it cool down naturally.

Abrasive

It’s a fact that a great quality abrasive is going to provide superior waterjet parts, yet most of the times it’s going to come in handy when working with finicky materials such as glass. You’ll find that greater mesh sizes can give some pretty smooth results with minimal microchipping on the edges.

At the end of the day, it’s very important how you approach glass cutting and that you always do it by the book. Sure, sometimes you may want to rush things in order to finish a project faster, but you will only do so at your own risk. So take your time to do what you have to do instead of getting your money and time wasted just so you can finish a project a few minutes earlier.
