Fiber Laser Marking ماكينة حفر بالليزر

Specification:
1 Laser Wavelength                                         1.06μm
2 Laser Power                                                  20W/30W/50W
3 Repeating Frequency                                  1.5-100KHz
4 Marking Area                                               100mm×100mm(F160)
5 Marking Line Width                                   ≥0.05mm
6 Marking Window Upgrade                    160mm x 160mm (F254 Lens)
290mm x 290mm (F420 Lens)
7 Min. Character Size                                    0.1mm
8 Marking Speed                                          ≤7000mm/s
9 Repeat Accuracy                                        ±0.003mm
10 M2                                                                ≤2.0
11 Laser source                                            Raycus-Max-Hans Mopa
12 PC Windows 7 Integrated 13
14 Available Ports Service/Ethernet/USB/Monitor/Keyboard/Keyboard/Mouse
15 Cooling Air –                                            CooledCooled
16 Complete Power Consumption            500W
17 Overall Dimension                                 760mm×610mm×1494mm
